Test Solutions - Software & Documentation Resources
- Click here to see model details and specifications for all USB & Ethernet controlled switch, programmable attenuator & test systems
| Documentation Type | Version | Link | Description / Instructions |
| Quick Setup Guide | OR |  |
How to connect and get started with Mini-Circuits' software controlled test systems |
| Programming Examples & Troubleshooting Guide | C0 | |
General examples and troubleshooting steps for a range of programming environments |
| Programming Example Downloads | Search Examples... | Search and download examples for a range of languages (including Python, LabVIEW, C#, VB & MatLab) | |
| VISA App Note | 1 | |
Instructions for controlling Mini-Circuits Test Equipment Using VISA |
| FAQ & Troubleshooting - Software | 25-Nov-19 | |
Frequently asked questions on working with Mini-Circuits software API |
| FAQ & Troubleshooting - LabVIEW | 25-Nov-19 | |
Frequently asked questions on working with Mini-Circuits software API in LabVIEW |
| FAQ & Troubleshooting - Hardware | 25-Nov-19 | |
Frequently asked questions on working with Mini-Circuits test equipment |
| Software EULA | Current | |
End user licence agreement for Mini-Circuits software downloads |
| Product Family | Format | Supported Models / Series |
| ZTM / ZTM2 Modular Test Systems | Rack-Mount |
ZTM series ZTM2-32, ZTM2-34 or later, ZTM2-xSPnT models (2023 or later) |
| ZTM2 Modular Test Systems (Legacy) | Rack-Mount | ZTM2-1 to ZTM2-31, ZTM3-33, ZTM2-xSPnT models (up to 2023) |
| RCM Modular Test Systems | Benchtop | RCM series |
| Programmable Attenuators (1,4 & 8 Channels) | Benchtop | eDAT, RUDAT, RCDAT, RC4DAT, RC8DAT, ZVVA series |
| Multi-Channel Attenuator Racks | Rack-Mount | ZTDAT series |
| Mesh Network Emulators | Rack-Mount | ZTMN series |
| Full Fan-Out Matrices | Rack-Mount | ZT-mXRFn series |
| Mechanical Switch Boxes | Benchtop | RC, ZTRC series |
| Solid State Switches | Benchtop | eSB, RCS, U2C, USB series |
| Solid-State Switch Assemblies | Rack-Mount | ZTS series |
| 2 x n Switch Matrices | Rack-Mount | ZTVX series |
| Custom Switch Assemblies | Rack-Mount | ZT Custom series |
| Signal Generators | Benchtop | SSG series |
| Power Meters | Benchtop | PWR series |
| Integrated Frequency Counter & Power Meters | Benchtop | FCPM-6000RC |
| Frequency Counters | Benchtop | UFC-6000 |
| VNA (Vector Network Analyzer) | Benchtop | eVNA-63+ |
| ISM RF & Microwave Energy | Rack-Mount & Benchtop | ISC, ZHL-2425-250X+, RFS, RFX |
| ZVA Variable Gain Amplifiers | Benchtop | ZVA series variable gain amplifiers |
| Evaluation Boards | Digital step attenuators, VCOs, synthesizers |
All products are shipped with the latest available firmware and an update is usually not required. Mini-Circuits occasionally makes firmware update files available as a courtesy to add additional features or correct known issues. Please contact testsolutions@minicircuits.com for details.
