RF Test and Measurement Solutions - Portable Test Accessories

Lab Accessories & Test Tools

Model Number	Case Style	Description	Length (in)

HT-2-SMA	MY-1E-004 LxD 2.5x0.318	Extended SMA Wrench to reach SMA connectors in tight spaces	2.5
HT-4-SMA	MY-1E-005 LxD 4x0.318	Extended SMA Wrench to reach SMA connectors in tight spaces	4.0
HT-8-SMA	MY-1E-008 LxD 8x0.318	Extended SMA Wrench to reach SMA connectors in tight spaces	8.0
TRQ-516-08	MY2727 LxD 6.44x.563	Break-over Torque Wrench 8 in-lbs for SMA, 1.85mm, 2.4mm, 2.92mm, 3.5mm connectors	6.44
TRQ-N20-8	MY3253 LxD 6.97x0.559	Break-over Torque Wrench 8 in-lbs for N-Type connectors	6.97
TRQ-N20.6-8	MY3254 LxD 6.97x0.559	Break-over Torque Wrench 8 in-lbs for N-Type connectors	6.97
TRQ-N34-8	MY3255 LxD 7.09x0.559	Break-over Torque Wrench 8 in-lbs for N-Type connectors	7.09

Model Number	Description	Connector Type	Indicator Type	Interface Measurement Compliance	Gauge Resolution (inch)	Gauge Calibration Accuracy (inch)	Gauge Repeatability (inch)

ACUDIAL-N	Set of two dial gages to check correctness of interface mating dimensions of pin from Ref plane Of” N” male and female connector	N	Dial	MIL-PRF-39012 Class 2	0.0001	0.00075	0.0001
ACUDIAL-SMA	Set of four dial gages to check correctness of interface mating dimensions of pin and dielectric from Ref plane of “SMA” male and female connector	SMA	Dial	MIL-PRF-39012 Class 2	0.0001	0.00075	0.0001

Model Name	Frequency(GHz)		Impedance Ω	Connector Type	Contents
Model Name	Low	High	Impedance Ω	Connector Type	Contents
KSOLT-63-S+	DC	6	50	SMA	Short, Open & Load standards (f + m) Matched Thru standards (f<>f, f<>m, m<>m) Torque wrench
KSOLT-63-N+	DC	6	50	N-type	Short, Open & Load standards (f + m) Matched Thru standards (f<>f, f<>m, m&<>m) Torque wrench
