Solid State RF Switch Modules

Compact Signal Routing Solutions for Your Test Setup

Mini-Circuits’ solid-state switch modules are ideal for applications requiring fast switching times and bullet-proof reliability. Options from SPDT to SP16T are available from stock, with some models operating up to 67 GHz. Our solid-state design approach achieves superior isolation performance, combining some of the benefits typically reserved to mechanical switches with the speed and longer life of semiconductor-based designs. Ideal for sensitive test applications where signal selectivity is critical!

Frequency ranges spanning DC to 67 GHz
Various combinations of SPDT, SP4T, SP6T, SP8T, SP10T and SP16T switches
Very high isolation, up to 110 dB
Switching as fast as 250ns
USB, Ethernet & SPI control
Daisy-chain interface allows control of multiple units through a single connection

BROWSE CATALOG CONTACT US

Browse Catalog

Catalog Products

For special & custom products, please contact us.

New Products

Announcements

Solid State Switches | USB / SPI / I²C / TTL | DC to 67 GHz

Model Number	Case Style	Switch Type	Control Interface	Number of Switches	F. Low (MHz)	F. High (MHz)	Insertion Loss (dB), Typ	Isolation (dB), Typ	VSWR (:1), Typ	Transition Time (usec), Typ	Supply Voltage (V), Typ	Max Input Power (W)

ESB-1SP2T-A673	WP3211 LxWxH 3.500x0.984x0.925	SPDT	USB / Daisy chain	1	100	67000	4	45	1.5	0.6	USB (5V)	0.5
ESB-1SP4T-A673	WP3335 LxWxH 5.224x0.984x0.866	SP4T	USB / Daisy chain	1	100	67000	6	45	1.4	0.6	USB (5V)	0.5
RCS-1SP2T-A673	NR3502 LxWxH 2.620x3.350x0.575	SPDT	USB / Ethernet / Daisy chain	1	100	67000	4.5	45	1.5	0.6	USB (5V)	0.5
RCS-1SP4T-A673	NR3472 LxWxH 2.620x3.350x0.575	SP4T	USB / Ethernet / Daisy chain	1	100	67000	6.5	45	1.5	0.6	USB (5V)	0.5
TTL-1SP4T-183	RB3522 LxWxH 5.00x1.50x0.70	SP4T	TTL	1	100	18000	3	65	1.5	0.05	-5 & +5	1
TTL-1SP8T-183	RB3408 LxWxH 6.750x1.500x0.700	SP8T	TTL	1	100	18000	4	70	1.5	0.05	-5 & +5	1
U2C-1SP2T-63VH	NR2563 LxWxH 3.0x2.0x0.475	SPDT	USB / I²C / SPI	1	10	6000	4	110	1.3	0.7	USB (5V) or 12-24	2
U2C-1SP4T-852H	RB2502 LxWxH 3.75x2.50x.60	SP4T	USB / I²C	1	2	8500	4	60	1.4	0.6	USB (5V)	0.8
USB-1SP16T-83H	RB2574-2 LxWxH 10.98x2.50x0.60	SP16T	USB / TTL / Daisy chain	1	1	8000	7.5	100	1.3	5	USB (5V)	1
USB-1SP2T-A44	UE3202 LxWxH 3.45x1.70x0.60	SPDT	USB / Daisy chain	1	100	43500	3	55	1.5	0.01	USB (5V)	0.25
USB-1SP2T-183	NR3244 LxWxH 2.30x2.00x0.575	SPDT	USB / Daisy chain	1	100	18000	2.5	65	1.2	0.005	USB (5V)	0.25
USB-1SP2T-34	NR3244 LxWxH 2.30x2.00x0.575	SPDT	USB / Daisy chain	1	100	30000	2.8	60	1.4	0.005	USB (5V)	0.25
USB-1SP2T-673	WP3211 LxWxH 3.500x0.984x0.925	SPDT	USB / Daisy chain	1	100	67000	4	35	2.0	5	USB (5V)	0.5
USB-1SP4T-183	NR3218 LxWxH 3.35x2.00x0.575	SP4T	USB / Daisy chain	1	100	18000	3.6	65	1.2	0.01	USB (5V)	0.25
USB-1SP4T-34	NR3218 LxWxH 3.35x2.00x0.575	SP4T	USB / Daisy chain	1	100	30000	4.5	60	1.4	0.01	USB (5V)	0.25
USB-1SP4T-A673	WP3335 LxWxH 5.224x0.984x0.866	SP4T	USB / Daisy chain	1	100	67000	6	45	1.4	0.6	USB (5V)	0.5
USB-1SP8T-183	NR3245 LxWxH 5.30x2.00x0.575	SP8T	USB / Daisy chain	1	100	18000	4.5	65	1.35	0.025	USB (5V)	0.25
USB-1SP8T-34	NR3245 LxWxH 5.30x2.00x0.575	SP8T	USB / Daisy chain	1	100	30000	5	80	1.6	0.025	USB (5V)	0.25
USB-1SP8T-183SP	NR3314 LxWxH 5.30x2.063x0.575	SP8T	USB / Daisy chain	1	100	18000	4.5	65	1.35	0.025	USB (5V)	0.25
USB-1SP8T-852H	QM2280 LxWxH 6.50x2.00x0.475	SP8T	USB / Daisy chain	1	10	8500	5	70	1.3	0.2	USB (5V)	1
USB-2SP2T-DCH	QM2468 LxWxH 4.58x2.00x.475	SPDT	USB / Daisy chain	2	DC	8000	1.4	50	1.2	10	USB (5V)	3.15
USB-2SP4T-852H	QM2605 LxWxH 8.42x2.00x0.475	SP4T	USB / Daisy chain	2	10	8500	3.5	80	1.4	5	USB (5V)	1
USB-4SP2T-852H	QM2279 LxWxH 8.42x2.00x0.475	SPDT	USB / Daisy chain	4	10	8500	3	70	1.35	0.2	USB (5V)	1
USB-SP4T-63	NR1982 LxWxH 2.25x1.50x.475	SP4T	USB	1	1	6000	1	50	1.2	3	USB (5V)	0.5
