TRS2-1T-75+

• 5 to 1200 MHz
• Low insertion loss, 1.0 dB typ.
• Good return loss, 20 dB typ.
• Low amplitude unbalance, 0.3 dB
• Power handling up to 0.25W

TC4-13TX+

• Top-Hat Transformer
• Wideband, 100 to 1000 MHz
• DC isolated
• Low insertion loss, 0.6 dB
• Low amplitude unbalance, 0.5 dB

TCM2-672X+

• Top-Hat Transformer
• 1700 to 6700 MHz
• Balanced transmission line
• Excellent return loss
• Aqueous washable

SYTX2-61HP+

• Surface Mount Transformer
• 10 to 60 MHz
• High power handling, 12.5W
• Low insertion loss, 0.3 dB
• Small size, 0.43 x 0.69 x 0.42"

TC4-122-75X+

• Top Hat, 75 ohms RF Transformer
• 40 to 1250 MHz
• Plastic base with leads
• Aqueous washable

TRS1.33-132-75+

• Top Hat, 75 ohms RF Transformer
• 25 to 1300 MHz
• Good return loss
• Flat insertion loss

TX4-62HP+

• RF Transformer
• High power/high DC current
• High impedance ratio 4:1
• Leadless surface mount
• 20 to 600 MHz

TXA4-512HP+

• RF Transformer
• High power input, 5 Watt max.
• Good amplitude unbal, 0.3 dB typ.
• Excellent phase unbalance 2 deg. typ.
• 30 to 512 MHz

SYTX4-13HP+

• RF Transformer
• high power input, 10 Watt max.
• good amplitude unbalance
• excellent phase unbalance
• balanced transmission line with secondary center tap
• 30 to 1000 MHz
